Camera |
Image Device |
1/3” 3 mega-pixel progressive scan CMOS sensor |
Lens |
3~10.5 mm vari-focal |
Angle of view: |
H: 91.2~25.5 degrees |
V: 68.4~19.1 degrees |
D: 114~31.9 degrees |
Min Illuminator |
Color: 0.5 lux @ 30 IRE |
B/W: 0 lux @ IR ON |
IR Illumination LED |
4 x high power IR LED, 850nm |
Built-in IR illuminators, effective up to 30 meters |
*The IR distance is based on the environment |
Effective Pixels |
2048 x 1536 pixels |
Image |
Video Encoder |
H.264 / MPEG-4 / M-JPEG |
High Resolution Mode |
H.264@ QXGA (2048 x 1536) |
MPEG4 @1080p |
MJPEG @D1 |
Frame Rate |
QXGA (2048 x1536): 20fps |
1080p (1920 x 1080): 30fps |
Quad-VGA (1280 x 960): 30fps |
720p (1280 x 720): 30fps |
D1(720 x 480): 30fps |
VGA (640 x 480): 30fps |
QVGA (320 x 240): 30fps |
Image Setting |
Brightness, sharpness, contrast, saturation, mirror, day/night mode, WDR, remote focus, text, time and image overlay |
Streaming |
Simultaneous multi-profile streaming |
M-JPEG streaming over HTTP |
Supports 3GPP mobile surveillance |
Controllable frame rate and bandwidth |
Constant and variable bit rate (MPEG4 / H.264) |
Audio |
Audio Streaming |
Two-way audio |
Audio Encoder |
G.711 μ-law |
Microphone |
External microphone input |
Audio Output |
External speaker supported |
Network and Configuration |
Network Standard |
IEEE 802.3 10BASE-T |
IEEE 802.3u 100BASE-TX |
Supported Protocols |
TCP/IP, IPv4, IPv6, UDP, ICMP, DHCP, NTP, DNS, DDNS, SMTP, FTP, HTTP, HTTPs, Samba, PPPoE, UPnP, Bonjour, RTP, RTSP, RTCP |
Security |
Password protection, IP address filtering, HTTPS |
QoS/DSCP |
Users |
5 clients on-line monitoring at the same time |
System Integration |
Application Programming Interface |
Open API for software integration |
ONVIF Compliant |
Alarm Triggering |
Intelligent video motion detection and external input |
3-zone video motion detection |
Alarm Events |
File upload via SD card, FTP, email and SAMBA. |
External output activation |
Configurable pre/post alarm buffering |
General |
Power Supply |
12V DC, 2A |
IEEE 802.3af Class 3 |
Power Consumption |
Max. 9W while IR LED is ON |
Max. 7W while IR LED is OFF |
Housing |
Weather-proof IP66-rated housing |
Operating Temperature |
-20~50 degrees C (32~122 degrees F) |
Operating Humidity |
20% ~ 85% (non-condensing) |
Weight |
1200g |
Dimensions (Φ x L) |
73 x 183 mm |
Emission |
CE, FCC |
Connectors |
10/100 Mbps Ethernet, RJ45 |
DC power jack |
Terminal block for 1 alarm input, 1 output |
External microphone input |
Audio out |
Micro SD/SDHC card slot (max. 32GB, class 10) |
